Throttle is activated through adjusting lift of valve core. Choke gate position is relayed to the choke console by a low-pressure air signal from the actuator of the choke. The cylindrical gate & seat can be reversed without removing choke from manifold. Hydraulic Drilling Chokes are used to control borehole pressure for drilling or well service operations.
Features:
• Abrasion resistance
• Suitable for H2S and CO2 work conditions
We supply the hydraulic drilling chokes available in all temperature and PSI levels according to A.P.I Specification 6A standards. It is available in flanged ends in standard bore sizes from 2 1⁄16” through 4 1⁄16” in working pressures of 5,000 psi and 15,000 psi.
Certifications:
(1) The product manufactured is certified by American Petroleum Institute for the following:
-
ISO 9001:2008
-
ISO/TS 29001standards
-
Specifications Q1

|

|

|
 |
Effective Date 8th Nov 2010 |
Effective Date 8th Nov 2010 |
Effective Date 8th Nov 2010 |
Expiry Date 8th Nov 2013 |
Expiry Date 8th Nov 2013 |
Expiry Date 8th Nov 2013 |
Reg. Date 8th Nov 2010 |
Reg. Date 8th Nov 2010 |
Reg. Date 8th Nov 2010 |
(2)Also, certified from T U V South Asia Private Ltd. for ISO 14001:2004 standards.
 |
 |
Effective Date 25th Nov 2010 |
Expiry Date 24th Nov 2013 |
26th Nov 2010 |
